Camera

Image Sensor

1/3" CMOS

Max. Resolution

2880 (H) × 1620 (V)

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Illumination Distance

Up to 10 m (32.81 ft) (IR)

Illuminator On/Off Control

Auto

Illuminator Number

1 (IR LED)

Angle Adjustment

Tilt: -5° to 80°
Pan: 0° to 350°

Lens

Max. Aperture

F2.0

Field of View

H: 74°; V: 41°; D: 88°

Intelligence

Human Detection

Yes

Video

Video Compression

H.265

Video Frame Rate

Main stream: 2880 × 1620@(1-25/30 fps)
sub stream: 640 × 360@(1-25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Resolution

5M (2880 × 1620); nHD (640 × 360)

Video Bit Rate

H.265: 40 kbps–4096 kbps

Day/Night

Auto(ICR)/Color/B/W

WDR

DWDR

Motion Detection

Yes

Image Rotation

0°/180°

Audio

Built-in MIC

Yes

Built-in Speaker

Yes

Audio Compression

G.711a

Network

Network Port

RJ-45 (10/100 Base-T)

Wi-Fi

IEEE 802.11b/g/n/ax 2.412-2.472 GHz,2.4G

Storage

Micro SD card (up to 256 GB)

Management Software

DMSS

Mobile Client

iOS;Android

Certification

Certifications

CE

Power

Power Supply

5 VDC, 1 A

Power Consumption

Basic: 1.9 W;
Max.: 3.8 W (live + IR + PT rotation)

Environment

Operating Temperature

–10 °C to +45 °C (+14 °F to + 113 °F)

Operating Humidity

≤95%

Structure

Casing Material

Plastic

Product Dimensions

φ84 mm × 123.8 mm (φ3.31" × 4.87")

Net Weight

206.5 g (0.46 lb)
